1.The automatic interlocking device for getting on and off the vehicle is used to interlock the getting on and off the vehicle to prevent danger caused by misoperation.2. Automatic emergency pump: When the main pump fails, the emergency system can send workers back to the ground3. Working platform emergency stop device is used for emergency stop operations and restricts boom operations4. Automatically limit the working range. When the working range reaches the specified value, the dangerous direction will be automatically limited.5. When the outriggers are not supporting the ground (soft legs), the lifting boom will restrict work in dangerous directions.6. Nighttime safety warning devices include engineering strobe lights and LED lighting on the vehicle.7. Square hydraulic outriggers have stronger bearing capacity and more stable ground support than traditional hydraulic outriggers.8. The eighteen-sided working arm has higher stability and can withstand greater loads.
Chassis | JiangLing Shunda / JAC Kangling / Isuzu |
Drive mode | rear drive |
No. of front tires | 2 |
No. of rear tires | 4 |
Braking method | Oil brake |
Cab number | single row 2 people |
Temperature control | air-conditioning |
Engie | Isuzu |
Power | 122P |
Emission | National 6 |
Total size | 5595*2000*2980mm |
Weight | 4495kg |
Bucket load | 200kg |
Max. working height | 27m |
Working range at max. working height | 3m |
Max. working range | 12m |
Working height at max. working range | 17m |
Leg span (lateral) | 4140mm |
Leg span (longitudinal) | 4300mm |
Force extraction system | Mechianiclly operation |
Bucket size | 1400*710*1200mm |
Boom type | 5 section hexagonal working boom |
Rotation | 360° |
Legs | Front V rear H type, individually adjustable |
No. of variable amplitude cylinders | 1 |
Boom telescopic structure | Cylinder and wire rope type |
Wheel base | 3360mm |
Max. driving speed | 110km/h |
Approach angle | 27° |
Departure angle | 11° |
Operation way | remote control/manual operation |
Emergency operation | automatic emergency operation |
Control system | CAN bus control system |
Leveling system | automactic leveling |
Control voltage | 12V |
